Overview:

The entire machine is constructed from high-quality 304 stainless steel, ensuring food safety.

The blades are sharp and have undergone special heat treatment, offering high speed, strong cutting performance, and excellent durability. The machine is fully waterproof, and the conveyor belt can be rinsed directly with water.

Parts are easy to disassemble and can be washed with water. The machine features a conveyor belt connected to the discharge port, ensuring that cut ingredients are neatly arranged and can be loaded directly into trays without further sorting.

The machine operates smoothly with excellent stability, low noise, and a low failure rate. To meet diverse customer needs, the speed of the feed conveyor belt is controlled via variable frequency regulation, accommodating the cutting of ingredients of varying thicknesses (1–30 mm).

The casters allow the operator to easily move the machine to different workstations. The push-button control panel enables adjustment of blade and conveyor belt speeds according to different products and customer requirements.

Technical Specifications:

Model: TY-140

Machine Dimensions: 1615 x 550 x 1150 mm

Conveyor Discharge Height: 90 mm

Machine Weight: 191 kg

Input Belt Width: 140 mm

Power Consumption: 2.17 kW

Output Belt Width: 150 mm

Power Supply: 220 V

Cutting Thickness: 1–30 mm

Feed Height: 100 mm

Processing Capacity: 500–2000 kg
