Key Performance and Structural Features:

Fully servo-controlled; bag length is set and cut instantly without the need for idle run adjustment, achieving the desired result in a single step to save time and film.

Fully automated bag length sensing capability.

Human-machine interface (HMI) and PLC control system ensure more stable operation, allowing any parameter to be adjusted without stopping the machine.

Automatic fault diagnosis function with clear fault display.

High-sensitivity photoelectric mark tracking and digital input of sealing and cutting positions ensure greater accuracy.

Positioning stop function prevents blade sticking and minimizes film waste.

Chinese and English touchscreen display for intuitive and simple operation.

Product Specifications:

Model: TY-280XF

Cutting Method: Top and bottom cutting

Packaging Speed: Depends on the product

Bag Width: 60–280 mm

Maximum Film Width: 580 mm

Machine Dimensions: (L) 4000 × (W) 960 × (H) 1550 mm

Machine Weight: 650 kg

Power Supply: 220 V, 50/60 Hz, 3.5 kW
