Technical Specifications:

Model: TY-800

Vacuum chamber dimensions: 420x435x75mm

Sealing power: 500W

Minimum absolute pressure in vacuum chamber: 1 kPa

Sealing bar length: 400mm

Sealing width: 10mm

Voltage: 220V

Overall Dimensions: 540 x 490 x 950 mm

Vacuum Pump Power: 1 kW

Weight: 65 kg

Vacuum Pump Flow Rate: 2.0 L/min

Vacuum Chamber Material: Stainless Steel

Center-to-Center Distance Between Sealing Bars: 340 mm
