Product Description:

The TY series vacuum packaging machines complete the entire process—including vacuuming, sealing, printing, cooling, and venting—simply by pressing the vacuum chamber lid, following the preset program.

Vacuum-packed items are protected against oxidation, mold, insect infestation, and moisture, thereby extending the product’s shelf life.

Technical Specifications:

Model: TY-800

Vacuum Chamber Dimensions: 840 x 840 x 160 mm

Heat Sealing Power: 1600 W

Minimum Absolute Pressure in Vacuum Chamber: 1 kPa

Heat Sealing Bar Length: 800 mm

Heat Sealing Width: 10 mm

Voltage: 380V

Overall Dimensions: 1800 x 1000 x 1040 mm

Vacuum Pump Motor Power: 3000 W

Weight: 400 kg

Vacuum Pump Airflow: 100 L/min

Vacuum Chamber Material: 304 Stainless Steel

Center-to-Center Distance Between Sealing Bars: 750 mm
