Overview:

Electrical Components: Chint Group; Motor: YX3-112M-6 manufactured by Shanghai Huabin Electric Motor Co., Ltd. Equipment Description: Both the base plate and cover plate are made of SUS304 stainless steel.

Application: This machine is designed to be used in conjunction with international standard 200L meat carts, automatically tilting and discharging raw meat and auxiliary ingredients from the cart into the hopper.

Technical Specifications:

Model: TY-200

Drive Type: Screw-type

Lifting Capacity: 200 kg

Lifting Height: 1.85 m

Lifting Speed: 5.12 m/min

Power Rating: 1.5 kW

Dimensions: Approx. 1290 x 640 x 2450 mm

Weight: Approx. 300 kg
