Applications:

The earliest single-unit plate-type ice maker in China, widely used in seafood buffets, hot pot buffets, and small supermarket chains.

Working Principle:

When the compressor operates, the refrigerant undergoes suction, compression, expansion, condensation (liquefaction), and throttling. It then evaporates and absorbs heat at a low temperature of -10 to -18°C in the evaporator.

Chilled water at 0°C continuously condenses into an ice layer on the surface of the evaporator, which is at a lower temperature. When the ice layer reaches a certain thickness and the refrigerant’s evaporation temperature reaches the preset temperature, the defrost solenoid valve is activated—typically using a heat pump mechanism for defrosting—before the next cycle begins.

Features:

All major components are sourced from countries with leading refrigeration technology, such as the United States, Germany, Japan, and Denmark. The machine offers fast ice production, energy efficiency, environmental friendliness, and excellent hygiene. The one-piece stainless steel ice blade is manufactured in a single-mold process without welding. It remains strong and durable even after prolonged rotation and scraping, producing uniform ice with virtually no powder. It offers advantages such as energy efficiency, environmental friendliness, and fast ice output.

Technical Specifications:

Model: TY-2B5

Dimensions: 1000 x 850 x 1750 mm

Output: 0.5 kg/h

Voltage: 220 V, 2-phase, 50 Hz

Power: 2.45 kW

Weight: 300 kg
