Technical Specifications:

Power Supply: 220V/50Hz–60Hz

Air Supply Pressure: 0.5–0.8 MPa

Power: 1100W

Air Consumption: ≥280 L/min

Motor: 24V/120W/18K

Air Inlet Hose Diameter: 10 mm

Conveyor Speed: 0–25 m/min

Vacuum Level: -0.05–0.088 MPa

Sealing Width: 10 mm

Vacuum Flow Rate: ≤160 L/min

Sealing Tape Specifications: 1210 × 20 × 0.22 mm

Vacuuming Time: 0.5–20 s

Temperature control range: 0–280°C

Gas supply hose diameter: 8 mm

Conveyor belt specifications: 3300 × 320 × 2 mm

Gas supply pressure:<1 MPa

Heating tube specifications: 180 × 10 mm × 450 W × 2

Sponge belt specifications (outer): 1450 × 16 × 12 mm

Sponge belt dimensions (inner): 870/830 × 16 × 12 mm

Conveyor height from ground: 680–850 mm

Maximum bag dimensions: 450 × 350 × 15 mm

Conveyor load capacity: 5 kg

Machine weight: 160 kg

Machine dimensions: 1850 × 800 × 1110 mm
