System: Ungey System

Motor: Japanese Ulvac, compliant with CE standards

Drive mechanism: Direct drive via a Taiwanese-brand gearbox; no belts or chains; high torque

Materials for meat grinding tube, feed screw, and screw nut, plus machine surface: Stainless steel

Machine surface finish: Glass-blasted matte finish to prevent visual fatigue during prolonged use, "

Grating plates: Imported from Italy; Double-sided cutting blades: Imported from Germany;"

Motor overload protection with automatic shutdown and reset function: "

Comparison between the triple-grating, double-blade model and the traditional single-blade, single-grating model: "

Single-blade, single-grating model: High cutting resistance per pass; if the grating plate thickness is 6mm or less, grinding time is typically prolonged, causing the meat temperature to rise and increasing the risk of spoilage.

Three-screen, three-blade model: Utilizes coarse, medium, and fine screens for cutting, making mincing easier while producing finer, more attractive results. Processing time is reduced, and the meat is less prone to spoilage.

Double-sided blades: Two double-sided blades perform four cuts in total, saving effort compared to the single-blade model’s single cut and producing a more uniform texture;

The meat is ground through multiple screens of varying sizes, preserving the meat’s granular texture and visual appeal.

Equipment Specifications:

Power: 3.0 kW

Voltage: 380 V

Capacity: 800–1000 kg/h

Equipment Weight: 119 kg

Dimensions: 710 × 970 × 1050 mm
