Overview:

The HY-420A bone saw is specially designed to save space for retail stores, restaurants, and fresh food vendors. Though compact and elegant, it retains the authentic craftsmanship of a master artisan.

The aluminum alloy body features a powder-coated finish that offers a smooth texture and is easy to clean.

The pneumatic, adjustable material clamping mechanism provides consistent, stable, and reliable grip—no irregularly shaped product can escape its grasp.

The automatic feed system frees up your hands, ensuring safe operation and meat hygiene.

The pneumatic air-blowing cleaning system ensures the saw blade maintains lasting power and smooth operation. The Swiss-imported saw blade operates at high speeds with quietness and stability beyond your imagination.

Composite hardwood saw blade scrapers provide a reliable guarantee for extended blade life. The smart control panel features 5 programmable memory settings.

During operation, cutting thickness can be dynamically adjusted within a range of ±0.1mm, ensuring consistently precise cuts.

Technical Specifications:

Model: TY-6580

Power Supply: Three-phase, five-wire 380V, 50Hz

Processing Dimensions: 590 x 450 x 150 mm

Output: 8–13 cuts per minute

Overall Dimensions: 1350 x 1850 x 1700 mm

Power: 3.5 kW

Cutting Thickness: 1–80 mm
