Features:

The machine frame is made of SUS304 stainless steel for durability

A microswitch at the discharge port ensures safe operation

The speed of the rotating blades on the conveyor belt for leafy vegetables is controlled by a variable frequency drive (VFD) for independent control

Cuts root vegetables into thick slices, thin slices, strips, and cubes

Finished shapes: slices, square strips, and cubes

Functions:

Root vegetables: Potatoes, taro, sweet potatoes, melons, bamboo shoots, onions, eggplants—cut into cubes, strips, or slices

Leafy vegetables: Kelp, celery, Chinese cabbage, napa cabbage, spinach, scallions, garlic, melons, and other long, strip-shaped items—cut into slices or strips.

Technical Specifications:

Model: TS-1

Machine Dimensions: 1160×530×1000mm

Slicing Thickness: 2-6mm

Strip Size: 3×3mm or larger

Cutting Length: 1-60mm

Belt Width: 120mm

Shredding Size: 2-6mm

Slice Dimensions: 2–6 mm

Dice Dimensions: 8 mm, 10 mm, 12 mm, 15 mm, 20 mm

Capacity: 300–1000 kg/h

Power Supply: 220 V single-phase, 50 Hz

Motor Power: 1 HP + 1 HP + 1/2 HP

Weight: 135 kg
