Overview:

Unidirectional rotation with adjustable speed. Controlled by a time relay; parameters for total time, operating time, and pause time are selectable.

Supports a cycle mode of: tumbling-pause-tumbling-pause.

Features continuous vacuum and intermittent vacuum functions.

Equipped with a built-in water-ring vacuum pump and an integrated water tank. Includes an air filter to prevent materials from being sucked into the vacuum pump.

Drum positioning function for easy cleaning.

Entirely constructed from high-quality 304 stainless steel with a sandblasted finish.

Technical Specifications:

Model: TY-1000

Dimensions (L/W/H in mm): 1760 x 1020 x 1575

Material: SUS304

Capacity (L): 1000

Production Capacity (kg/batch): 500

Power (kW): 2.95

Power Supply (V/Hz): 380/50

Rotational Speed (r/min): Fixed speed / Variable frequency speed control

Vacuum Level (MPa): -0.06 to -0.08

Total Weight (kg): 480
