The TY series meat grinders utilize the high-speed rotating blades to mince meat and ingredients into ground meat or meat paste. They can also mix ingredients, ice chips, and water evenly with ground meat or meat chunks.

Technical Specifications:

Dimensions (L/W/H): 2400 mm / 1420 mm / 1300 mm

Cutter Speed (r/min): 126/1800/3600 rpm

Material: SUS304 All-Stainless Steel

Bowl Speed (r/min): 8/12 rpm

Bowl Capacity (kg/batch): 70–80 kg/batch

Power Supply Voltage (V): 380V/50Hz

Mixing Bowl Capacity (L): 125 liters

Power (kW): 23 kW

Number of Chopping Blades: 6

Total Machine Weight (kg): 1380 kg
